| MOQ: | 1 |
| 価格: | USD1000-USD6000/SET |
| 標準梱包: | 通常のフィルムとカートン付き |
| 配達期間: | 預金の15日後 |
| 支払方法: | T/T |
| 供給能力: | 30セット/月 |
1.Premium Water Wash Spray Booth: High-Efficiency Water Curtain Coating System
Designed for high-volume liquid painting and continuous production lines, our Industrial Water Wash Spray Booth delivers unparalleled overspray collection and environmental compliance. Instead of relying solely on dry filter pads that clog quickly, this system utilizes a continuous, flowing curtain of water to capture airborne paint particles before they reach the exhaust stack.
As the contaminated air is drawn through the water curtain, the paint overspray is forced into a highly efficient washing chamber where it is scrubbed out of the air and drops into the collection tank below. This not only ensures a pristine finish on your manufactured parts by maintaining superior cabin airflow, but it also dramatically reduces filter replacement costs and minimizes environmental impact.
2.Key Features & Benefits
1.Continuous Water Curtain: A smooth, uninterrupted waterfall across the front stainless-steel baffle catches the majority of paint overspray on contact.
2.Multi-Stage Air Scrubbing: Air is pulled beneath and behind the curtain through washing chambers, ensuring maximum particulate separation before the air is exhausted.
3.Constant Airflow & Zero Clogging: Unlike dry booths where airflow drops as filters clog, the water wash system maintains a consistent draft, ensuring uniform paint application and operator safety.
4.Heavy-Duty Construction: Built with rigid galvanized steel for the cabin and premium stainless steel for the water curtain and tank to prevent rust and corrosion.
5.Simplified Sludge Management: Paint solids float or sink in the main tank, allowing for easy skimming and sludge removal, extending the life of the recirculating water.
6.Energy-Efficient Centrifugal Fans: Equipped with high-performance, spark-resistant exhaust fans designed to handle high static pressure with lower energy consumption.
3. Technical Specification
| Parameter | Specification |
| Product Type | Water Wash Spray Booth / Water Curtain Paint Booth |
| Cabin Construction Material | High-grade folded galvanized steel panels |
| Water Curtain Material | 304 / 316 Stainless Steel (Corrosion resistant) |
| Overspray Filtration Method | Front water curtain impingement + Internal scrubber washing |
| Airflow Direction | Crossdraft or Semi-Downdraft (Customizable) |
| Exhaust Fan Type | Spark-resistant centrifugal fan (Explosion-proof motor optional) |
| Water Circulation System | Heavy-duty, clog-resistant industrial centrifugal water pump |
| Lighting System | Roof/Wall mounted Class 1 Div 2 (Explosion-proof) LED fixtures |
| Control System | Centralized control panel (Fan, Pump, Lighting, E-Stop) |
| Sludge Collection | Integrated floor tank with accessible skimming/clean-out zones |
| Environmental Compliance | Meets standard VOC and particulate exhaust regulations |
| Dimensions & Sizing | Custom-engineered to client production line requirements |
4. Ideal Applications
1.High-Volume Manufacturing: Ideal for continuous conveyor lines and batch production.
2.Automotive & Aerospace: Component painting, primer, and clear-coat applications.
3.Woodworking & Furniture: Spraying lacquers, varnishes, and heavy adhesives.
4.Heavy Machinery & Metal Fabrication: Coating large-scale industrial equipment where high paint output is required.
