Large capacity conveyor chain for industrial coating Roller coating production line

Large capacity conveyor chain for industrial coating Roller coating production line

Product Description

System Overview

• Designed to handle diverse workpieces and deliver high-quality finishes

• Comprises a complete setup including pre-treatment, spray stations, oven, heat source, electronic controls, and roller conveyor

Workpiece Handling & Coating Process

• Workpieces are transported on custom tooling fixtures

• Uniform coating is achieved through controlled roller rotation

Control & Operational Features

• Utilizes advanced PLC control for automated operation

• Offers stepless speed adjustment and multiple induction probes for precision

• Includes manual control buttons at key points for operational flexibility

Application & Adaptability

• Ideal for varied manufacturing environments

• Combines automation and manual control to accommodate different production needs

The roller coating line is suitable for medium-volume, regular workpieces; such as automobile wheels, turntables, ovens, etc.

As a kind of automated spraying equipment, the roller spray painting line mainly consists of six major components:

pre-treatment equipment, spray painting equipment, oven,heat source system, electronic control system, roller conveyor line, etc.

It can place the workpiece on the tooling fixture of the conveyor line, and send the workpiece into the spraying area

for spraying through the rotation of the roller. The roller line generally,uses an accumulation system. Each station has

a manual control button, and each completed workpiece can be lowered to the spraying area. Processed at the next station.

The entire line adopts PLC control, stepless speed adjustment, and is equipped with multiple induction probes and control buttons.

The electric roller is a new type of driving equipment in which the motor and reducer are placed inside the roller body.

It is mainly used in fixed and mobile belt conveyors,replacing traditional motors and separate drive equipment with

reducers outside the driving roller.





Peace Environmental Protection always adheres to the core principle of "quality first, honest service" and provides
excellent solutions for customers in the field of environmental protection equipment. The factory is located in
Guangzhou City, Guangdong Province.
The company's main products include environmental protection equipment such as spray booth,coating line,painting line
and waste gas and wastewater treatment,if you have any inquiry,please leave the inquiry here directly,will be respond to you within 12 hours
We will make the exact Design Drawing,Design Case in words,and Quotation in detail,just waiting for you leave the message here.
